FLEXIBILITY SP700AVi platforms address the critical demands of fast set up and product changeover through flexible automation strategies that streamline assembly throughput.
AUTOMATION Features include closed-loop print head control, bi-directional board clamping and laser-guided tooling to ensure fast, efficient and accurate tooling support set up.
ASSURANCE Speedprint platforms are refined, robust, design-optimised products built to last. Be assured that SP700AVi Series printers will perform identically in a decade as they do when new.
OPTIONS The SP710avi printer can deploy the unique Advanced Dispense unit (ADu+) to dispense a wide range of media including paste and glue. It can also support S-Track for process-wide traceability.
FLEXIBILITY SP700AVi platforms address the critical demands of fast set up and product changeover through flexible automation strategies that streamline assembly throughput.
AUTOMATION Features include closed-loop print head control, bi-directional board clamping and laser-guided tooling to ensure fast, efficient and accurate tooling support set up.
ASSURANCE Speedprint platforms are refined, robust, design-optimised products built to last. Be assured that SP700AVi Series printers will perform identically in a decade as they do when new.
OPTIONS The SP710avi printer can deploy the unique Advanced Dispense unit (ADu+) to dispense a wide range of media including paste and glue. It can also support S-Track for process-wide traceability.
Top performance for rapid returns
Sitting at the top of our product range, the SP700AVi Series is engineered to deliver streamlined performance at low ownership costs for high, medium and low-volume production applications.
Unrivalled accuracy
Exceptional repeatability and print accuracy stem from meticulous alignment. Speedprint’s patented Dual Roving camera (DRc) technology precisely aligns the board and stencil, and checks for solder paste presence on the stencil before printing. DRc innovations include SmartCal, a zero-cost straightforward calibration facility that lets operators validate the process in 30 seconds or less. SmartCal helps to maximise and maintain your process window, delivering optimum performance for the life of the platform.
Assurance
Flexible automation is at the very centre of the platform. SP700AVi Series printers are comprehensively equipped with almost every parameter fully programmable.
Advanced features
- Cycle time 11.5 seconds standard, 8 seconds option
- Print speed 5mm/sec to 250mm/sec
- Fully programmable board stop
- Alignment repeatability to 12.5µm @ 6-Sigma 2Cpk
- Full process repeatability to 20µm @ 6-Sigma 2Cpk
- Highly efficient vacuum-assisted under stencil cleaning: fully programmable, wet or dry, with or without vacuum
- Auto stencil load and eject to streamline product changeover
- Closed loop dual squeegee control for print process optimisation.
- Fully programmable print parameters
- Defect prevention with programmable Optical Paste Bead Management. Verifies solder paste presence on the stencil. Alerts to insufficient volume. Safeguards quality
- SmartCal cost-free instant process calibration
- SPI communication
- Maximum positional accuracy with 1-micron resolution linear encoders on all axes
